We produce accurate, fabrication-ready engineering and steel detailing from concept through to manufacture. We deliver clash-free 3D BIM models, fabrication shop sets, and CNC/DSTV data for fabricators and consulting engineers across South Africa.
From preliminary design layouts to fabrication-ready workshop packages, we cover structural, mechanical, civil, and specialized fabrication with absolute precision.
Comprehensive structural detailing for industrial warehouses, portal frames, workshops, overhead crane gantries, and complex architectural steel.
Heavy-duty mineral processing structures, material transfer chutes with ceramic/Hardox wear liners, ore bins, cyclones, and furnace ducting.
Pedestrian arch bridges, heavy overland conveyor galleries, multi-tier industrial pipe bridges, stair towers, and caged ladder systems.
Precision 3D mechanical modeling and fabrication detailing for heavy equipment, rail coil transfer cars, hydraulic presses, croppers, and transport trailers.
Transit station canopies (Gautrain, BRT), municipal water treatment facilities, pumpstations, reservoirs, concrete plinths, and holding tanks.
Dry dock caisson gates, marine barges, pontoon flotation units, stainless steel shark diving cages, pressure vessels, and fuel storage farms.
Every drawing and model below is from actual projects executed by our detailing team. Click any card to inspect full-resolution fabrication sheets, 3D assemblies, and GA drawings.
All drawings and models adhere strictly to South African National Standards and international fabrication codes.
The structural use of steel in South Africa (Parts 1 & 2). Standardized bolt spacings, edge distances & connection capacities.
Basis of structural design and actions for buildings and industrial structures. Dead, live, wind and seismic clearances.
Bending dimensions and scheduling of steel reinforcing for concrete structures, plinths and cast-in hold-down assemblies.
AISC 360 & BS EN 1090 execution of steel structures for international fabricators and offshore export projects.
Our structured 4-step detailing workflow guarantees zero clashes on site and seamless workshop fabrication.
We ingest your engineering drawings, architectural layouts, or 3D scan point clouds, verifying member sizing, gridlines, and connection criteria.
Every beam, column, plate, gusset, bolt, and weld is modeled in full 3D. Clash detection eliminates costly workshop fitting errors before steel is cut.
Automated extraction of fabrication sheets, assembly drawings, single-part DXFs, and NC1 machine files for beam drill lines and plate cutting beds.
Comprehensive erection General Arrangements (GAs), 3D anchor bolt layouts, bolt lists, and material cutting lists delivered in clean PDF and DWG formats.
Upload your drawings, markups, or scope documents for an official binding quote within 24–48 hours.
